· A intergral descent metering valve maintains a controlled and safe lowering of the load.
· The piston head seal design is borrowed from industrial technology providing a superior low and high pressure seal, giving better hold under severe load conditions
· Double polished chromed pistons allow for much tigher tolerances which reduces oil bypassing and ram scoring
· Air assisted lowering speeds up ram retraction
· Built in overloaded safety valve prevents damage due to excessive load
· All units come with 2 extensions…( 3 and 1.75”) and saddle adapter
50 ton (1st stage) – Low Ht 8.46” High Ht 13.07” Lift 4.61”
25 ton (2nd stage)- Low Ht 8.46” High Ht 17.56” Lift 9.09”
|
